ARC MELTING FURNACE
Small Bench-Top Arc Melting Furnace
Compact tabletop electric arc melting unit designed for laboratory research, material testing, and small-batch alloy sample preparation. Generates ultra-high temperature electric arcs between graphite electrodes and metal raw materials to melt high-melting-point metals efficiently. Features simple manual operation, fast heating response, and precise melting control. The lightweight structure requires minimal installation space and delivers stable performance for academic labs and small-scale material development projects.
Specifications
-
Input Voltage: AC 220V/380V, 50/60Hz
-
Rated Power: 10kW
-
Arc Working Temperature: 1700℃–2000℃
-
Melting Capacity: 0.5–2kg per batch
-
Melting Time: 2–5 minutes
-
Operation Mode: Manual bench-top operation
-
Cooling Method: Air cooling + water cooling
-
Dimension: 450 × 350 × 420mm
-
Net Weight: 35kg
Applicable Materials
Small batches of steel, copper, precious metals and alloy samples
Product Features
-
Compact bench-top design, portable and space-saving
-
Instant arc ignition, ultra-fast heating speed
-
Simple manual operation, suitable for laboratory and small workshop use
Safety Protection
Over-current, over-heat and short-circuit automatic protection
Manual Tilting Arc Melting Furnace
Industrial tilting-type arc melting furnace equipped with a manual pouring mechanism. Creates high-temperature electric arcs to melt steel scrap, iron, and non-ferrous alloy materials. The manual tilting structure allows smooth, controlled pouring of molten metal with low failure rates. Built with a heavy-duty reinforced frame and heat-resistant furnace lining for long service life. Ideal for small foundry workshops requiring flexible batch melting and low-cost production operations.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 25kW
-
Arc Working Temperature: 1800℃–2100℃
-
Melting Capacity: 5–10kg per batch
-
Melting Time: 6–10 minutes
-
Tilting Mode: Manual mechanical tilting
-
Cooling Method: Circulating water cooling
-
Dimension: 950 × 600 × 1100mm
-
Net Weight: 160kg
Applicable Materials
Carbon steel, copper alloys, brass, bronze and common non-ferrous metals
Product Features
-
Manual tilting structure, low failure rate and easy maintenance
-
Stable arc discharge, uniform melting effect
-
Cost-effective, ideal for small batch casting
Safety Protection
Over-current, over-voltage, over-temperature and water shortage protection
Medium-Sized Industrial Electric Arc Furnace
Standard industrial-grade arc melting furnace optimized for medium-volume metal smelting and casting. Uses powerful electric arc heating to rapidly melt bulk metal scraps and alloy materials. Supports adjustable power output and flexible melting cycles to adapt to different metal compositions. Equipped with basic dust reduction and heat dissipation structures for safe daily operation. Widely used in general machinery casting, metal recycling, and standard alloy production processes.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 50kW
-
Arc Working Temperature: 1850℃–2200℃
-
Melting Capacity: 20–30kg per batch
-
Melting Time: 10–15 minutes
-
Tilting Mode: Electric tilting
-
Cooling Method: Closed circulating water cooling
-
Dimension: 1400 × 800 × 1350mm
-
Net Weight: 480kg
Applicable Materials
Cast iron, carbon steel, alloy steel, stainless steel and various industrial alloys
Product Features
-
Industrial grade stable arc melting system
-
Electric tilting for efficient and smooth pouring
-
Suitable for medium-volume factory continuous production
Safety Protection
Full automatic protection against over-current, over-temperature, water shortage and phase loss
Hydraulic Tilting Arc Melting Furnace
Automatic hydraulic tilting arc melting furnace designed for stable and large-volume molten metal pouring. Features a fully hydraulic driving system for smooth, precise furnace body tilting without shaking or splashing. High-power electric arc heating ensures thorough and uniform melting of ferrous metals and special alloys. Comes with overheat protection and anti-leakage design, improving operational safety and production consistency. Suitable for medium and large foundry production lines.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 80kW
-
Arc Working Temperature: 1900℃–2200℃
-
Melting Capacity: 50–80kg per batch
-
Melting Time: 12–18 minutes
-
Tilting Mode: Full hydraulic automatic tilting
-
Cooling Method: Industrial closed water cooling system
-
Dimension: 1850 × 1000 × 1600mm
-
Net Weight: 720kg
Applicable Materials
Various steel materials, high-purity copper alloys and industrial casting metals
Product Features
-
Hydraulic tilting system, stable, safe and labor-saving pouring
-
Strong arc energy, fast melting and high production efficiency
-
Reinforced furnace body for long-term industrial operation
Safety Protection
Multi-protection system with hydraulic anti-overflow, overheat, over-current and water shortage alarm
High-Precision Laboratory Arc Melting Furnace
Precision arc melting equipment dedicated for scientific research, new alloy development, and high-purity material smelting. Provides stable, concentrated electric arc heating with accurate temperature regulation to avoid material contamination and component deviation. Adopts closed melting chamber design to reduce oxidation and gas impurities. Compact structure with intelligent parameter setting functions, perfect for university laboratories, material research institutes, and precision sample manufacturing.
Specifications
-
Input Voltage: AC 220V/380V, 50/60Hz
-
Rated Power: 15kW
-
Temperature Accuracy: ±5℃
-
Arc Working Temperature: 1800℃–2300℃
-
Melting Capacity: 100g–5kg
-
Melting Time: 3–6 minutes
-
Cooling Method: Precision circulating water cooling
-
Dimension: 600 × 480 × 550mm
-
Net Weight: 68kg
Applicable Materials
Precious metals, high-purity alloys, experimental new materials and laboratory samples
Product Features
-
High-precision temperature and current control
-
Low oxidation, high-purity melting effect
-
Professional for material research, sample smelting and alloy development
Safety Protection
Intelligent precision over-temperature and overload protection system
Scrap Metal Recycling Arc Melting Furnace
Specialized arc melting furnace designed for waste metal recycling and remelting. Supports direct smelting of mixed steel scraps, iron scraps, and industrial metal residues with strong material adaptability. High-temperature arc reaction effectively removes impurities and refines molten metal. Optimized combustion and heat circulation system improves melting efficiency and reduces energy waste. Ideal for metal recycling factories and resource regeneration production lines.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 100kW
-
Arc Working Temperature: 1850℃–2150℃
-
Melting Capacity: 100–150kg per batch
-
Melting Time: 15–22 minutes
-
Tilting Mode: Hydraulic tilting
-
Cooling Method: Heavy-duty closed water cooling
-
Dimension: 2200 × 1200 × 1800mm
-
Net Weight: 950kg
Applicable Materials
Scrap steel, scrap copper, waste aluminum, recycled alloy materials and recycled industrial metals
Product Features
-
Strong impurity tolerance, specially designed for scrap metal recycling
-
High melting efficiency, suitable for large recycling production
-
Durable anti-corrosion furnace lining structure
Safety Protection
Anti-blocking, over-load, over-temperature and water shortage full protection
.jpg)
.webp)
High-Temperature Special Alloy Arc Melting Furnace
High-temperature enhanced arc melting furnace for processing high-melting-point special alloys including stainless steel, nickel-based alloys, and high-temperature resistant alloys. Features upgraded graphite electrode systems and thickened high-temperature furnace lining to sustain extreme working temperatures. Stable arc output ensures uniform alloy organization and high molten metal purity. Suitable for aerospace parts, mechanical equipment, and high-precision casting industries.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 90kW
-
Max Working Temperature: 2300℃
-
Melting Capacity: 15–25kg special alloy per batch
-
Melting Time: 12–18 minutes
-
Tilting Mode: Electric / Hydraulic optional
-
Cooling Method: High-pressure resistant circulating water cooling
-
Dimension: 1750 × 950 × 1580mm
-
Net Weight: 620kg
Applicable Materials
Titanium alloy, nickel-based alloy, tungsten alloy, molybdenum alloy and super high-temperature alloys
Product Features
-
Ultra-high temperature arc melting system for special metal smelting
-
Anti-oxidation and high-purity melting technology
-
Stable arc energy to avoid alloy component segregation
Safety Protection
Ultra-high temperature alarm, pressure protection, over-current and phase loss automatic shutdown
Energy-Saving Low-Consumption Arc Melting Furnace
Energy-efficient electric arc melting furnace optimized for power saving and environmental protection. Adopts improved arc stabilization technology to reduce invalid power consumption and heat loss. Equipped with intelligent power adjustment functions that automatically match energy output according to melting volume. Low noise operation and reduced flue gas emissions meet modern environmental production standards. Perfect for factories with strict energy consumption and emission control requirements.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 60kW
-
Energy Saving Rate: 25%–35% than traditional arc furnaces
-
Arc Working Temperature: 1750℃–2000℃
-
Melting Capacity: 30–40kg per batch
-
Melting Time: 11–16 minutes
-
Operating Noise: ≤58dB
-
Cooling Method: High-efficiency energy-saving water cooling
-
Dimension: 1500 × 850 × 1450mm
-
Net Weight: 530kg
Applicable Materials
Ordinary steel, cast iron, copper and brass alloys for regular casting
Product Features
-
Optimized arc power control, extremely low power consumption
-
Low noise and environmentally friendly operation
-
High thermal efficiency, reduces production costs greatly
Safety Protection
Intelligent energy-saving protection, overheating and overload automatic power-off
.webp)
Continuous Working Arc Melting Furnace
Long-cycle continuous operation arc melting furnace built for non-stop industrial production. Reinforced mechanical structure and durable electrode components support prolonged high-load working conditions. Features real-time temperature monitoring and automatic arc stabilization to maintain consistent melting quality during continuous batches. Excellent heat dissipation and safety protection systems minimize downtime. Designed for large-scale, high-yield foundry and metallurgy production.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 120kW
-
Continuous Working Time: 24-hour non-stop operation
-
Arc Working Temperature: 1850℃–2100℃
-
Melting Capacity: 80–100kg per batch
-
Melting Time: 14–20 minutes
-
Tilting Mode: Hydraulic automatic tilting
-
Cooling Method: Industrial grade full closed circulation cooling
-
Dimension: 2300 × 1250 × 1850mm
-
Net Weight: 1050kg
Applicable Materials
Mass production of carbon steel, alloy steel, copper alloys and casting raw materials
Product Features
-
Designed for 24-hour continuous industrial production
-
Continuous stable arc output without power attenuation
-
Heat-resistant and durable furnace body structure
Safety Protection
Long-term running protection system, real-time temperature and water pressure monitoring
Mini Vacuum Arc Melting Furnace
Vacuum environment arc melting furnace used for oxidation-free smelting of high-purity metals and rare alloys. Works in a closed vacuum chamber to isolate air, effectively eliminating oxidation, air bubbles, and slag in molten materials. Precise arc control ensures uniform melting of titanium alloys, precious alloys, and experimental metal materials. Compact vacuum structure with easy vacuum pumping and simple operation for high-end material processing.
Specifications
-
Input Voltage: AC 220V/380V, 50/60Hz
-
Rated Power: 12kW
-
Vacuum Degree: ≤0.08Pa
-
Arc Working Temperature: 2000℃–2400℃
-
Melting Capacity: 200g–3kg
-
Melting Time: 4–7 minutes
-
Cooling Method: Vacuum chamber water cooling
-
Dimension: 720 × 650 × 780mm
-
Net Weight: 120kg
Applicable Materials
High-purity metals, rare metals, vacuum alloy materials and laboratory high-end samples
Product Features
-
Vacuum melting environment, zero oxidation and ultra-high purity
-
Ultra-high temperature arc for refractory metal melting
-
Mini compact structure, professional for scientific research
Safety Protection
Vacuum leakage protection, over-temperature and arc abnormal protection
Intelligent Automatic Arc Melting Furnace
Smart automated arc melting furnace with digital control system for unmanned and standardized melting production. Supports automatic feeding, arc starting, constant temperature melting, and timed pouring functions. Real-time data monitoring displays temperature, power, and working status dynamically. The system self-adjusts parameters to stabilize melting quality and reduce manual errors. Suitable for modern intelligent foundry workshops requiring high automation levels.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 70kW
-
Control System: Full automatic PLC touch screen control
-
Arc Working Temperature: 1800℃–2150℃
-
Melting Capacity: 40–60kg per batch
-
Melting Time: 12–17 minutes
-
Tilting Mode: Program automatic hydraulic tilting
-
Cooling Method: Intelligent constant temperature water cooling
-
Dimension: 1650 × 900 × 1520mm
-
Net Weight: 600kg
Applicable Materials
Various industrial steel, copper alloys and standardized casting materials
Product Features
-
Fully automatic intelligent operation, one-key melting program
-
Automatic arc adjustment and temperature constant control
-
Data recording, fault self-diagnosis and intelligent monitoring
Safety Protection
Full intelligent linkage protection system with automatic alarm and emergency stop
.webp)
Heavy-Duty Large-Capacity Arc Melting Furnace
Large industrial heavy-duty arc melting furnace for bulk ferrous metal smelting and mass steel casting. Equipped with ultra-high power arc generating system to handle large-volume raw material feeding and rapid melting. Thickened anti-high-temperature furnace body and heavy-load supporting structure adapt to long-term industrial heavy-load production. Matched with complete dust removal, cooling, and safety interlock systems to ensure stable and efficient large-scale metallurgical production.
Specifications
-
Input Voltage: AC 380V 3 Phase, 50/60Hz
-
Rated Power: 180kW
-
Arc Working Temperature: 1900℃–2200℃
-
Melting Capacity: 250–300kg per batch
-
Melting Time: 20–28 minutes
-
Tilting Mode: Heavy-load full hydraulic automatic tilting
-
Cooling Method: Industrial heavy-duty closed water cooling system
-
Dimension: 3000 × 1600 × 2200mm
-
Net Weight: 1680kg
Applicable Materials
Large batch cast iron, carbon steel, alloy steel and various bulk industrial metal materials
Product Features
-
Heavy-duty industrial large-capacity design for mass production
-
Super strong arc energy, high melting efficiency and stable quality
-
Reinforced thickened furnace body, durable for long-term heavy load work
